2205 Duplex ASTM A789 SS Hydraulic Control Line Tubing 3/8" OD

2205 duplex stainless steel is smelted and manufactured in its solid-quenched structure in which the ferrite phase and the austenite phase are half of the stainless steel, referred to as 2205 stainless steel, also called 2205 duplex steel. The actual phase ratio is that ferrite occupies 45-55%, and the corresponding austenite occupies 55-45%. The excellent performance of 2205 duplex stainless steel is guaranteed by an appropriate ratio of two-phase structure.

2205 duplex stainless steel has excellent mechanical properties, corrosion resistance, and good weldability, and has a wide range of uses in the oil and gas industry, marine engineering, chemical industry and other industries. The length of the oil and gas pipelines laid by duplex stainless steel in the oil and natural gas industry has exceeded 850km, and most of them are 2205 duplex stainless steel seamless steel pipelines (some are S31803 duplex stainless steel pipelines and 2507 duplex stainless steel pipelines).

This product is mainly used to inject chemical reagents into oil and gas wells. Connect the 3/8" hydraulic control line to the downhole chemical injection valve, a certain concentration of cleaning chemicals can enter the chemical injection valve from the ground through the hydraulic control line and then be discharged into the underground pipeline, which can effectively remove tubing fouling.

Inspection & Test

1 .100 % PMI , Spectro Chemical Aanlysis Test for Raw Material

2 .100 % Dimension & Visual Examination

3 . Mechanical Properties Test Include Tension Test,Flaring Test ( For Seamless tube / pipe ) / Flange Test ( For Welded Pipe & Tube ) , Hardness Test , Reversed Flattening Test

4 .100 % Hydrostatic Test or 100 % NON - DESTRUCTIVE Test ( ET or UT )

5 . Radiographic Test for Welded Pipe ( shall be accordance with specification , or shall be as agreed upon between the purchaser and vendor )

6 . Straightness Test ( optional )

7 . Roughness Test ( optional )

8 . Intergranular Corrosion Test ( optional )

9 . Impact Test ( optional )

10 . Grain Size Determinations ( optional )

NOTES: ALL THE TESTS AND INSPECTION RESULT NEED TO BE SHOWED IN REPORTS ACCORDING TO STANDARD AND SPECIFICATION.

FAQ

Q1: Can you arrange the shipment?
A: Sure, we have permanent freight forwarder who can gain the best price from most ship company and offer professional service.

Q2: How long is your delivery time?
A: Generally it is 7-14 days if the goods are in stock. or it is 25-45 days if the goods are not in stock, it is according to quantity.

Q3. Can you provide customize service?
A: Yes.Pipes can be customized as per the customers' request.

Q4. How to ensure the quality?
A:Mill Test Certificate is supplied with shipment.
If needed, a Third Party Inspection is acceptable.

With the leading direction of producing High pressure extra long stainless steel control line tube(stainless steel coiled tubes), TIPTOP has become a high-tech industrial company integrating domestic research and development, production and sales. The company successfully developed a series of stainless steel testing cables in 2000. In recent years, the company has been committed to the research and development of duplex steel and nickel alloy control lines, and has been widely approved in the international market.

The company covers an area of 20,000 square meters and a building area of 12,000 square meters. The company has several stainless steel tube production lines, tube making units, tube drawing units, well-type electric furnaces, online vacuum light furnaces and other production equipment. The company also has a quality inspection center that meets the national stainless steel tube quality inspection requirements. The quality inspection center has a 300Mpa hydraulic test machine, tensile test bench, Vickers hardness tester, 500°C temperature resistance test furnace, eddy current flaw detector and a series of stainless steel products. Testing and inspection equipment to ensure the reliability and stability of the chemical and physical properties of stainless steel products.　

The company annually produces more than 3,000 tons of stainless steel control lines and other products, sales marked covers both domestic and overseas, for domestic, we are network-enterprise company of CNOOC, Petro China and Sinopec, as for international,it has been widely used in Middle East, Southeast Asia, South America, Australia and so on.　

On the premise of improving the quality of its own brand products, the company has continuously increased the research and development of new products, and has cooperated and actively invested with many domestic universities and scientific research institutions. In recent years, the company has passed the certifications of CCS, GL, DNV and other classification societies.

With our support,you will have:

1. Technical data, technical guidance and training for free
2. Professional engineer to the site for tracking service
3. "just-in-time supply"(that is, supply at any time according to the actual demand of customer), in this way customers achieve zero inventory, maximize profits.
4. Most favorable offer,we take "taking small profits" as the principle.
5. 100% qualified product,Our company will strictly follow the requirements of relevant technical standards , grasp various links of production, and ensure product performance .
6. sufficient after sales services.

We are looking forward to developing business with friends from home and abroad on the basis of equality and mutual benefits!welcoming your enquiries!
