    1" 2300 Feet ASTM A249 Welded Ss316L Coiled Tubing

    Ask Lasest Price
    Brand Name : TIPTOP
    Model Number : 304,316,625,825,2205,2507
    Certification : ISO 9001
    Price : Negotiable
    Payment Terms : T/T
    Supply Ability : 1000 tons per month
    Delivery Time : 10 days
    • Product Details
    • Company Profile

    1" 2300 Feet ASTM A249 Welded Ss316L Coiled Tubing

    Welded 316L Stainless Steel Coil Tube


    Tiptop is one of the largest Suppliers in China for high-quality Stainless Steel Coil Tube. The Stainless Steel Coil Tubing is available in lengths up to 2300 feet. SS coil tube straighteners make stainless steel coiled tubing installation faster and easier. Depending on the different applications the SS Coil Tubes are available in different sizes.


    Tiptop has a wide grade of Stainless Steel Coil Tube such as 304 Stainless Steel Coil Tube, 304L Stainless Steel Coil Tube, 316 Stainless Steel Coil Tube and 316L Stainless steel Coil Tube

    Stainless Steel Coil Tube Specification

    Outside Diameter1/16” to 3/4"
    Thickness0. 010" to 0.083”
    GradesTP - 304,304L,316,316L
    Seamless Coil Tubing SpecificationsASTM A213 (average wall) and ASTM A269
    Welded Coil Tubing SpecificationsASTM A249 and ASTM A269

    (WELDED 304/L OR 316/L)

    Outside Diameter (OD)Wall Thickness
    1/8” – 3/4”0.5mm – 4mm

    Stainless Steel Coil Tube Tolerance

    Stainless Steel Coil Tube Specifications – Restricted Tolerance Controls

    OD Tolerance: +0.005/-0 in.

    Hardness: Maximum 80 HRB (Rockwell)

    Wall Thickness: ±10%

    Chemistry: Min. 2.5% Molybdenum


    Stainless Steel Coil Tube Chemical Composition

    The below table shows the chemical composition of the used for Stainless Steel Coil Tubes:

    GRADESUNSCMnPSSiCrNiMoTiNbN
    TP304S304000.0820.0450.03118.0-20.08.0-11.0
    TP304LS304030.03520.0450.03118.0-20.08.0-13.0
    TP316S31600.0820.0450.03116.0-18.011.0-14.02.0-3.0
    TP316LS316030.03520.0450.03116.0-18.010.0-14.02.0-3.0

    Stainless Steel Coil Tube Mechanical Properties

    MaterialHeatTemperureTensile StrengthYield StrengthElongation %, Min
    TreatmentMin.Ksi (MPa), Min.Ksi (MPa), Min.
    º F(º C)
    TP304Solution1900 (1040)75(515)30(205)35
    TP304LSolution1900 (1040)70(485)25(170)35
    TP316Solution1900(1040)75(515)30(205)35
    TP316LSolution1900(1040)70(485)25(170)35

    Application

    Industrial use: heat exchanger, boiler, petroleum, chemical, fertilizer, chemical fiber, pharmaceutical, nuclear power.
