    Bright 25.4MM Welded ASTM Coiled Control Line Tubing

    Ask Lasest Price
    Brand Name : TIPTOP
    Model Number : 825
    Certification : ISO 9001
    Price : Negotiable
    Payment Terms : T/T
    Supply Ability : 1000 tons per month
    Delivery Time : 10 days
    • Product Details
    • Company Profile

    Bright 25.4MM Welded ASTM Coiled Control Line Tubing

    ASTM Alloy Steel Coiled Control Line Tubing


    Detailed product description
    1.Specification:Stainless steel coil tube coiled tube coil tubing
    2.Type: welded or seamless
    3. Standard: ASTM A269, ASTM A249,
    4. Stainless steel coil tube OD: 6mm to 25.4MM
    5.Length:600-3500MM or as per customer's requirment. not welding
    6. Wall thickness: 0.2mm to 2.0mm.
    7. Tolerance: OD: +/-0.01mm; Thickness: +/-0.01%.
    8.Surface: Bright or anneald
    9. Material: 304, 304L, 316L, 321, 301, 201, 202, 409, 430, 410,alloy 625 825 2205 2507 etc.
    10. Packing: LCL wooden case poly bay,FCL steel self or poly bay
    11. Test :Yield strength, tensile strength, hydrapress measurement
    12.Guarantee:The third party (for example :SGS TV ) cetification ect.
    13. Application:

    • Down hole tubes
    • Subsea umbilical's
    • Process constructions
    • General control system
    • Steam supply lines
    • Gas transport lines
    • Instrumentation



    All the Chemical Composition and Physical Properites for Stainless Steel as flowing:

    Chemical Composition,%
    StandardASTM A269ASTM A789ASTM B704
    MaterialSS 304SS 304LSS 316SS 316LDuplex 2205Super Duplex 2507Incoloy 625Incoloy 825
    UNSS30400S30403S31600S31603S32205S32750N06625N08825
    C0.080.0350.080.0350.030.030.10.05
    Mn222221.20.51
    P0.0450.0450.0450.0450.030.0350.015...
    S0.030.030.030.030.020.020.0150.03
    Si111110.80.50.5
    Ni8.0-11.08.0-12.010.0-14.010.0-15.04.5-6.56.0-8.0min 58.038.0-46.0
    Cr18.0-20.018.0-20.016.0-18.016.0-18.022.0-23.024.0-26.020.0-23.019.5-23.5
    Mo......2.00-3.002.00-3.003.0-3.53.0-3.58.0-10.02.5-3.5
    N............0.14-0.200.24-0.32......
    Cu...............0.5...1.5-3.0
    Fe5min 22.0
    Al0.40.2
    Ti0.40.6-1.2
    Cb+Ta3.15-4.15...

    MaterialHeat treatmentTemperure F (C) Min.Hardness
    BrinellRockwell
    TP304Solution1900 (1040)192HBW/200HV90HRB
    TP304LSolution1900 (1040)192HBW/200HV90HRB
    TP316Solution1900(1040)192HBW/200HV90HRB
    TP316LSolution1900(1040)192HBW/200HV90HRB

    ODWall
    (inch)
    MaterialsStandardWorking Pressure
    (MPa)
    Length
    1/8"0.02,0.028,0.035Austenitic steel 304L (UNS S30403)
    Austenitic steel 316L (UNS S31603)
    Duplex 2205 (UNS S32205 & S31803)
    Super Duplex 2507 (UNS S32750)
    Incoloy 825 (UNS N08825)
    Inconel 625 (UNS N06625)
    ASTM-A 269
    ASTM-A 632
    ASTM-A 789
    ASTM-B 704
    60-120 MpaCustomized
    3/16"0.02,0.028,0.035,0.049
    1/4"0.02,0.028,0.035,0.049,0.065.0.083
    5/16"
    3/8"
    1/2"
    * OD: Up to 1 inch
